The Weight Of FRP Single Hydraulic Prop

Date:2020-04-21     Label:

FRP Single Hydraulic Prop

Single Hydraulic Prop

Hydraulic Prop

The single hydraulic prop is a big family. The editor of Shandong China Coal Group would like to talk about the "glass fiber reinforced plastic single hydraulic prop" as a member of the single hydraulic prop group. The weight of the glass fiber reinforced plastic single hydraulic prop as the supporting handle of the support industry has always been a mystery. The following editors lead everyone to uncover the mysterious veil of the glass fiber reinforced plastic single hydraulic prop and understand the weight of the glass fiber reinforced plastic single hydraulic prop.



Weight of FRP single hydraulic prop:



In fact, the glass fiber reinforced plastic single hydraulic prop produced by our company has the characteristics of corrosion resistance, light weight and easy operation. The weight is only about 40% of similar products, which can greatly reduce the labor intensity of the operator and improve work efficiency. The glass fiber reinforced plastic monolithic pillar is a constant-resistance pillar with external liquid supply, which is manufactured by our company using special non-metallic materials.



The Weight Of FRP Single Hydraulic Prop

Weight of FRP single hydraulic prop: 22.5KG



Large height: 2800mm



Small height: 2230mm



Working stroke: 570mm



Rated working resistance: 30KN



Rated working hydraulic pressure: 3.8MPa



Initial support force: 30KN



Inner diameter of hydraulic cylinder: 100mm



Working medium: emulsion, hydrostatic water



FRP single hydraulic prop is a kind of temporary support equipment. It is a new type of product for temporary support in roadway excavation and roadway maintenance in the coal mine industry. This product uses emulsion as the working medium, but due to the anti-corrosion of key parts The process, therefore, has alkali resistance and acid resistance, and is suitable for various working environments. If you want to know more professional knowledge about FRP single hydraulic prop, please feel free to leave a message with us online.

+

+
